Innera Classic, a fancy in table power station ideal for meeting tables, inducing purity and integrity by fitting tightly to the table surface. Designed to be used also in fully closed position while the equipment can be plugged in. The Innera Classic is ideal for meeting room tables to be part of every surrounding: from offices, meeting rooms, convention halls, call centres, restaurants, hotels, labs, hospitals and many more. INSTALLATION CONFIGURATIONS In Desk /In Table it mainly being placed in meeting room table, conference tables, desk and fine surfaces.
Power & Temperature: Operating voltage: 230VAC 50VHz Maximum current: 16A Work Temperature: up to 70°C Structure & color: Flush, solid and durable structure, you will find Innera Classic is reliable unit with long life expectation. Innera Classic is available in Silver anodized cover - black sockets and end caps. Custom colors available on demand – minimum order will be requiered. Materials: cover - aluminium, sockets - PC. Modules & combination: The Innera Classic can be configured with a combination of power, data, communication, or any other Keystone system component. Cable and connection to power: The Innera Classic is supplied with 0.4 meter cable (HO5VV-F 3x1.5mm2) with male GST 18/3 connector. In order to connect the product to power you should buy the power cable separately. Testing: 100% testing continuity, polarity, insulation & earth Certification: SII test certification Warranty: 3 years Warranty by German registered company Installation: Power saw, Power drill and hole cutter required, please read the installation instruction prior to installation. Packing: each item in a box
| Catalog No | Model | Description | Length (L) mm | Width (W) mm | Height (H) mm |
| 0769978897769 | IC-33 | 3 IL sockets | 222 | 158 | 80 |
| 0769978897776 | IC-32 | 2 IL sockets & 2 keystones | 232 | 158 | 80 |
| 0769978897783 | IC-44 | 4 IL sockets | 265 | 158 | 80 |
| 0769978897790 | IC-43 | 3 IL sockets & 2 keystones | 274 | 158 | 80 |
| 0769978900568 | IC-42C | 2 IL sockets , 2.4A USB Charge, 2 keystones | 274 | 158 | 80 |
| 0769978897813 | IC-55 | 5 IL sockets | 308 | 158 | 80 |
| 0769978897820 | IC-54 | 4 IL sockets & 2 keystones | 317 | 158 | 80 |
| 0769978900582 | IC-53C | 3 IL sockets, 2.4A USB Charge, 2 keystones | 317 | 158 | 80 |
| 0769978897868 | IC-65 | 5 IL sockets & 2 keystones | 361 | 158 | 80 |
| 0769978897875 | IC-64 | 4 IL sockets & 4 keystones | 361 | 158 | 80 |
| 0769978900612 | IC-64C | 4 IL sockets , 2.4A USB Charge, 2 keystones | 361 | 158 | 80 |
| 0769978900650 | IC-86C | 6 IL sockets , 2.4A USB Charge, 2 keystones | 447 | 158 | 80 |
| 0769978897936 | IC-85 | 5 IL sockets & 6 keystones | 447 | 158 | 80 |
| 0769978900667 | IC-85C | 5 IL sockets , 2.4A USB Charge, 4 keystones | 447 | 158 | 80 |
